Midea 11DSNA-A-1301 - Page 11

9
L
R
H
Model R(mm)
L(mm)
H(mm)
Dimension of installation hole(mm)
MS11D-09HRDN1-MN5W
92 170 45
￠65
MS11D-09CRDN1-BN10W
MS11D-09HRDN1-BN10W
MS11D-09CRDN1-MN5W
MS11D-12CRDN1-MN10W
95 170 45
MS11D-12HRDN1-MN10W
MS11D-12CRDN1-BN10W
MS11D-12HRDN1-BN10W
MS11D-18CRDN1-MN10W
80 100 45
MS11D-18HRDN1-MN10W
Model R(mm)
L(mm)
H(mm)
Dimension of installation hole(mm)
MS11D-22CRDN1-MN10W
163 293 45 ￠65
MS11D-22HRDN1-MN10W
H
L
R
