Buttons and Functions
1
4
2
3
Turbo
5
8
9
12
6
7
10
11
13
14
Model:
RG10B10(B)/BGEF(20-28°C).
RG10B(B)/BGEF & RG10B(B1)/BGEFU1
( Fresh feature is not available)
RG10B2(B)/BGCEF
(Cooling only models, AUTO mode
and HEAT mode are not available)
Description
ON/OFF
No.1
No.3
No.4
No.5
No.6
No.8
No.2
No.7
No.9
No.10
Turn the unit on or o.
OK
Used to confirm the selected functions
TEMP.
Decreases temperature in 1°C (1°F) increments. Min. tem-
perature is 17°C (62°F)
TIMER
Set timer to turn unit on or o
FAN SPEED
No.11
TEMP.
Increases temperature in 1°C (1°F) increments. Max. tem-
perature is 30°C (86°F).
(For model of RG10B(B1)/BGEFU1, press together &
buttons at the same time for 3 seconds will alternate the
temperature display between the °C & °F).
SET
MODE
Auto > Cool > Dry > Heat > Fan
No.12
No.13
No.14
No.15
SLEEP
LOCK
Press together these two buttons simultaneously for 5 seconds
to lock the keyboard. Press together these two buttons for 2
seconds to unlock the keyboard.
NOTE: HEAT mode is not supported by the cooling only
appliance.
SWING
Starts and stops the horizontal louver movement. Hold
down for 2 seconds to initiate vertical louver auto swing
feature(some units).
CLEAN
Used to start/stop the Self Clean or Active Clean function.
Clean
Turbo Clean
LED
Turns LED display & air conditioner buzzer on and o
LED
TURBO
Reach desired temperature in shortest possible time.
Turbo
Fresh/UV lamp > Follow Me > AP mode >Fresh/UV lamp
*
*
*
[*]: Model dependent
Saves energy during sleeping hours.
Auto > Low > Med > High > Fan
SHORTCUT
Used to restore the current settings or resume previous
settings.
41
