Service Manual_2018-V1.0
18
1）Lift up the division plate with a proper force and pull it
out towards yourself;
Refrigerator Fruit box cover
Refrigerator Fruit box cover
8.3 Light system
The light at the top of refrigerator chamber
1）Push the lampshade inner and take it down.
2）Take down the screw on LED light panel, then light.
3) Rmove the connecting harness terminals on LED light
panel and take down the LED light panel.
8.4 Air duct components refrigerating chamber
Air duct components refrigeratingchamber
Air duct components refrigeratingchamber
8.5 Air duct components in freezing chamber and fan motor
Disassembly and installation of Air duct
Disassembly and installation of Air duct
