Midea CS11M-09HRFN1-MX0W User Manual

28
IPM board,
202302141237
P F C - L 2
[ 1 . 6 ] 2 0 14 .1 0. 16
EU-KFR105W/BP2T3N1-350(767).D.13.MP2-1
PFC-L1
EARTH
+
C N 55
T O- MA IN
W
V
U
IPM2
IPM1
IC1424C08
C N 54
L - I N 2
N - I N 2
O U T F A N ( D C )
IC1
CN53
power supply
connect to the terminal
208-230V AC
CN54
CN51CN52
PFC
inductance
terminal
CN58
EATTH
-
+
210-300VDC (Running)
CAPACITOR Voltage
290-330VDC (standby)
CN55
TO MAIN
CN19
connect to DC fan motor
U
V
W
10-200VAC (running)
0VAC (standby)
connect to the compressor
U
V
W
10-200VAC (running)
0VAC (standby)
CN57
Debug
