Midea CS11M-18HRFN1-MT0W

63
2
Fan ass’y
How to remove the fan
ass’y.
1) After remove the
panel plate following
procedure 1, remove
the hex nut fixing the
fan and then remove
the fan.
2) Unfix the hooks and
then open the electronic
control box cover.
○
1
○
2
compressor
T3,T4,T5 sensor
Motor
Electronic expansion valve
4 way valve
