Midea CS11M-18HRFN1-MT0W

65
3) Pull out connectors of
the condenser coil temp.
sensor(T3),outdoor
ambient temp. sensor(T4)
and discharge temp.
sensor(TP).
4) disconnect the
electronic expansion
valve wire
5) Remove the
grounding screw.
6) Remove the
Wires (1,2,3). Then
remove the electronic
control box.
○
3
○
4
○
5
○
6
