Midea CS11M-18HRFN1-MT0W - Page 79

77
4)Disconnect the pressure
switch connector.
5) Disconnect the
electronic expansion valve
wire from the control board
6) Remove the ground
wires .
7) Remove the
wires(1,2,3 or L1,L2,S).
Then remove the
electronic control box.
○
6
○
7
○
5
○
4
