维修手册 Service Manual, 2019 v1.0
4 / 16
2.3 螺钉拆卸 Screw disassembly
松开后网螺钉并取下后网，然后松开
并取出后壳 8 颗螺钉
Loosen the rear mesh screws and
remove the rear mesh, then loosen and
remove the 8 screws of the rear shell
2.4 后壳的拆卸 Rear shell disassembly
向后壳方向用力拍。让前后壳扣位脱开。
Press backward in the direction of the shell and
pull the front and rear buttons off.
