8
8 Insert the two ice maker mounting screws into the holes in the freezer
wall. Turn each screw clockwise five times.
9 Use needle nose pliers to remove the terminal cover located at the top
of the freezer by first pulling down one side of the cover, then pulling
down the other side. Save the terminal cover for future use in case the
ice maker is removed.
Ice maker
mounting screws
Terminal
Terminal cover
Ice Maker
