WIRED CONTROLLER DISPLAY
12345
7
9
10
11
12
13
4151
68
Fig. 1 - Wired Controller Display
1. Operation mode indicator
2. Fan speed indicator
3. Left−right swing indicator
4. Up−down swing indicator
5. Not Available
6. Not Available
7. FOLLOW ME function indicator
8. Turbo/Auxiliary Heat function indicator
9.
_C / _F indicator
10. Temperature display
11. Lock indicator
12. Room temperature indicator
13. Clock display
14. On/Off timer
15. Timer display
