Midea MCD-24HRFN1-M(C)

319
ass’y.
1) After remove the panel
plate following procedure 1
2) Remove the nut fixing
the fan,and remove the
fan.
3) Unfix the hooks and
then open the
electronic control box
cover (4 hooks).
4) Remove 6 screws on
the electronic control
board and then turn over
the electronic control
board.
○
2
fan
Electronic control box
compressor
