113
2 Fan
assembly
How to remove the fan
assembly.
1) Remove the top cover,
right front side panel and
front panel from item 1.step
1~4
2) Remove the hex nut fixing
the fan.
3) Remove the fan.
4) Remove the cover of
electrical control box cover.
5) Disconnect the fan motor
②
④
4s
Screws of
terminal board
