Midea MCH3U-27PHH2 User Manual

117
7) Remove the hex nuts and
washers fixing the
compressor to bottom
plate.
8) Lift the compressor.
5 Reactor How to remove the reactor
1) Perform work of item 1,2
2) Unfasten the connector
between IPM and reactor.
3) Remove two screws of
cover of inductance, and
remove the cover of
inductance
4) Disconnect two pieces of
wires connected from the
cover of inductance.
5) Remove four screws of
reactor, and remove the
reactor.
⑦
Screws of
cover of
inductance
Screws of
reactor
