9.3.6 Refrig
erant Leakag
e Detection diagnosis
and solution(EC)
Error Code
EC
Malfunction
decision
conditions
Define the evapor
ator coil temp.T
2 of the compress
or just starts
running as Tcool.
In the beginning 5 minu
tes after the
compressor st
arts up, if T2
＜
T
cool
－
2
°C(
Tcool
－
35.6
°F)
does not
keep cont
inuous 4
seconds and this situatio
n happens 3 times, the di
splay area will
show “EC”
and AC will turn off.
Supposed cause
s
●
T2 sensor fault
y
●
Indoor PCB fault
y
●
System problem
s, such as leakage o
r blocking.
T
rouble sho
oting:
40
42
