Midea MCHSU-48CSH2

25
4. Service Space
4.1 Indoor Unit
Duct Units
Ensure enough space required for installation and maintenance.
200mm(7.87in) or more
300mm(11.81in) or more
600mmx600mm/23.62inx23.62in
Check orifice
All the indoor units reserve the hole to connect the fresh air pipe. The hole size as following
Cassette Units
Unit: mm/inch
39.3
98.43
11.42
39.3
10.24
6.30in
4.92in
3.15mm
3.54mm
