Midea MDRB424FGE - Page 11

07
EN
3. Dismantle the middle hinge, the screws, the screws hole caps and remove the
freezer door.
4. Dismantle the bottom hinge, hole caps and screws, Install the bottom hinge
shaft on other side of the bottom hinge, then install the hinge on the other
side.
shaft
shaft
hole cap
screw cap
screw
5. Dismantle the screws, sleeve pipe and stopper on the lower end cover of the
two door bodies, and install them successively on the other side of the door
bodies (the stopper needs to be replaced from the additional bag). Then
remove the upper end cover of the cooler door and switch the wire harness
with a sleeve pipe to the other side of the door body. Finally install the sleeve
pipe of the upper hinge on the cooler door in the hole on the other side of
upper end cover of the cooler door.
