10) The picture after completion is shown as below
8)Exchange the F:bottom hinge and F:upper hinge ,then install them according to below steps,
and install the top hole cover and lower hole caps.
9) for 180°，
freezer door
Remove the two fixed blocks of freezer door and rotate them
and install them on other side of .
（The picture above is only for reference. The actual configuration will depend on
the physical product or statement by the distributor）
12
F:upper hinge
F:bottom hinge
hole cover
180°
fixed block
hole caps
Step 1:
install l eft botto m hinge
Step2:
put refri gerator
door on lef t bottom
hinge ver tically
Step 3:
install l eft upper h inge
To Next Page
