MCAC-VTSM-2017-01 Four-way Cassette
62
Specifications
Model
MDV-D56Q4/N1-D
MDV-D71Q4/N1-D
MDV-D80Q4/N1-D
Power supply
1 phase, 220-240V, 50Hz
Cooling
Capacity
kW
5.6
7.1
8
Input
W
75
82
97
Rated current
A
0.41
0.52
0.52
Heating
Capacity
kW
6.3
8
9
Input
W
75
82
97
Rated current
A
0.41
0.52
0.52
Indoor fan motor
Model
YDK60-6F-3
YDK80-6E-2
YDK80-6E-2
Type
AC
Input (H/M/L)
W
65/59/49
80/69/55
82/73/55
Capacitor
uF
3
3
3.5
Speed (H/M/L)
r/min
610/540/460
710/600/480
760/660/530
Indoor coil
Number of rows
2
Tube pitch(a) × row
pitch(b)
mm
21×13.37
Fin spacing
mm
1.5
Fin type
Hydrophilic Aluminum
Tube outside dia. and
type
mm
Ф7, Inner groove Tube
Coil length × height ×
width
mm
1961×168×26.74
Number of circuits
8
Indoor air flow (H/M/L)
m
3
/h
864/755/658
1157/955/749
1236/973/729
Sound pressure level (H/M/L)
dB(A)
42/38/35
45/42/39
45/42/39
Indoor unit
Dimension (W × H × D)
mm
904×230×840
Packing (W × H × D)
mm
955×260×955
Net/Gross weight
kg
26/30
Panel
Dimension (W × H × D)
mm
950×54.5×950
Packing (W × H × D)
mm
1035×90×1035
Net/Gross weight
kg
6/9
Refrigerant type
R410A
Throttle
Type
Electronic expansion valve
Design pressure(H/L)
MPa
4.4/2.6
Pipe connections
Liquid pipe
mm
Φ9.53
Gas pipe
mm
Φ15.9
Drain pipe
mm
ODФ32
Controller
Wireless remote controller
Notes:
1. Nominal cooling capacities are based on the following conditions: return air temperature: 27°CDB, 19°CWB, and outdoor
temperature:35°CDB, equivalent ref. piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions: return air t temperature: 20°CDB, outdoor temperature:
7°CDB, 6°CWB, and equivalent ref. Piping: 7.5m (horizontal)
