DM16-01.01.25en Floor Standing MFM
55 Service manual
Appendix2
Unit: ℃‐‐‐KDischargetemp.sensortable
‐20 542.7 20 68.66 60 13.59 100 3.702
‐19 511.9 21 65.62 61 13.11 101 3.595
‐18 483 22 62.73 62 12.65 102 3.492
‐17 455.9 23 59.98 63 12.21 103 3.392
‐16 430.5 24 57.37 64 11.79 104 3.296
‐15 406.7 25 54.89 65 11.38 105 3.203
‐14 384.3 26 52.53 66 10.99 106 3.113
‐13 363.3 27 50.28 67 10.61 107 3.025
‐12 343.6 28 48.14 68 10.25 108 2.941
‐11 325.1 29 46.11 69 9.902 109 2.86
‐10 307.7 30 44.17 70 9.569 110 2.781
‐9 291.3 31 42.33 71 9.248 111 2.704
‐8 275.9 32 40.57 72 8.94 112 2.63
‐7 261.4 33 38.89 73 8.643 113 2.559
‐6 247.8 34 37.3 74 8.358 114 2.489
‐5 234.9 35 35.78 75 8.084 115 2.422
‐4 222.8 36 34.32 76 7.82 116 2.357
‐3 211.4 37 32.94 77 7.566 117 2.294
‐2 200.7 38 31.62 78 7.321 118 2.233
‐1 190.5 39 30.36 79 7.086 119 2.174
0 180.9 40 29.15 80 6.859 120 2.117
1 171.9 41 28 81 6.641 121 2.061
2 163.3 42 26.9 82 6.43 122 2.007
3 155.2 43 25.86 83 6.228 123 1.955
4 147.6 44 24.85 84 6.033 124 1.905
5 140.4 45 23.89 85 5.844 125 1.856
6 133.5 46 22.89 86 5.663 126 1.808
7 127.1 47 22.1 87 5.488 127 1.762
8 121 48 21.26 88 5.32 128 1.717
9 115.2 49 20.46 89 5.157 129 1.674
10 109.8 50 19.69 90 5 130 1.632
11 104.6 51 18.96 91 4.849
12 99.69 52 18.26 92 4.703
13 95.05 53 17.58 93 4.562
14 90.66 54 16.94 94 4.426
15 86.49 55 16.32 95 4.294 B(25/50)=3950K
16 82.54 56 15.73 96 4.167
17 78.79 57 15.16 97 4.045
R(90℃)=5KΩ±3%
18 75.24 58 14.62 98 3.927
19 71.86 59 14.09 99 3.812
