Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
94
No. Part Name Qty BOM code No. Part Name Qty BOM code
1 Column 4 201290100384 41.1
4-way valve
1 201600600110
2 About the protective screen 4 201290100347 41.2
Pressure controller
1 202301800843
3 Network Rail fixed plate II 2 201290100349 41.3
Pipe joint
2 201601200004
4 Vertical beam in the frame 2 201290100386 42
Evaporator tube assembly
output
1 201690191322
5 Roof rack crossbar 2 201290100377 42.1
Pressure controller
1 202301800842
6 I sealed connector condenser 3 201290100378 43
Evaporator tube assembly
output
1 201690191323
7 Vertical beam roof rack 2 201290100383 43.1
Pressure controller
1 202301800842
8 Condenser sealed connector II 3 201290100381 44
Evaporator tube assembly
output
1 201690191321
9 Roof rack beam welding parts 2 201290100359 44.1
Pressure controller
1 202301800842
10 Top cover 6 201195300051 45
Welding together pieces of
the base
1 201290100376
11 Rear Panel II 1 201290100366 46
Left panel II
1 201290100365
12 Condenser output tube II 3 201690101357 47
Strengthened beams II
2 201290100370
13 In lane bridge I 2 201290100353 48
I left panel
3 201290100369
14
Block I installed electronic
control box
2 201290100364 49 Panel fasteners II 8 201290100372
15
Block III electronic control box
installed
2 201290100362 50 Triangular reinforcement 12 201290100387
16 Rear Panel I 1 201290100367 51 Trunking II 1 201290100361
17
Block II Electronic Control Box
Installation
2 201290100363 52 II trunking cover 1 201290100360
18 Electric door 2 201290100374 53
Enter the evaporator tube
assembly
1 201690191313
19
Air-cooled electronic control
box assembly module
1 203390190012 53.1 Electronic expansion valve 1 201601300018
19.1
Welding together pieces of
electronic control box
1 201290100390 54
Enter the evaporator tube
assembly
1 201690191312
19.2
Electrical mounting plate I
1 201290100388 54.1
Electronic expansion valve
1 201601300018
