Midea MGCSL-F30W/RN1 User Manual

MCAC-ATSM-2011-12 Air-cooled modular chiller unit 50Hz
13
Model MGCSL-F30W/RN1 MGCSL-D30W/RN1
Cooling Capacity
kW 30 30
Btu/h 102,300 102,300
Heating Capacity kW 32 32
Power supply V/Ph/Hz 380-415/3/50
Power supply
Manual switch A 50
Fuse A 36
Compressor
Type Fixed speed Digital Scroll + Fixed speed
Quantity Pieces 1+1 1+1
Model ZP67KCE-TFD-522
ZPD67KCE-TFD-532/
ZP67KCE-TFD-522
Brand Copeland
Capacity W 16200×2
Input W 5200×2
Rate current(RLA) A 9.1×2
Locked rotor Amp(LRA) A 74×2
Power input
Cooling kW 10 10
Cooling rated current A 16.3 16.3
Heating kW 9.8 9.8
Heating rated current A 16 16
Max. Input consumption A 13.4
Max. Current A 22.5
Refrigerant
Type R410A
Weight kg 3.5×2
Refrigerant control EXV
Condenser
(Air side)
Air side heat-exchanger type Fin-coil
Quantity of fan motor Pieces 1
Air flow volume ×10
3
m
3
/h 12
Fan motor input kW 0.55
Evaporator
(Water side)
Water side heat-exchanger type Double-pipe
Water resistance loss kPa /
Water inlet/outlet pipeline inside
normal diameter
mm DN40
inch 1-1/2”
Water flow volume m
3
/h 5.2 5.2
Max. Pressure MPa 1
Water pipe connection type Flexible joint
Dimension
Net(W×H×D)
mm
1514×1865×841
inch
59.6×73.4×33.1
Packing(W×H×D)
mm
1590×2065×995
inch
62.6×81.3×39.2
Weight
Net weight kg 430
Operation weight kg 450
Connection wire
Power wire mm
2
×No. 10×4+6×1
Signal wire mm
2
×No. 0.75×3-core with shielding
Control type Wired controller
