Horizontal louver
auto swing display
Vertical louver auto
swing display
Sleep mode display
Turbo mode display
Fresh feature display
Follow me feature
display
Not available for
this unit
Not available for
this unit
Not available for
this unit
Self clean feature
display
Silence feature
display
Transmission Indicator
Lights up when remote
sends signal to indoor
unit
ON/OFF display
Appears when the unit is turned on,
and disappears when the it is turned off.
This display is blank when
operating in FAN mode.
LOCK display
Indicates that the LOCK
function is on.
Fan speed display
Displays selected fan speed:
TIMER ON display
Displays when TIMER
ON is set
TIMER OFF display
Displays when TIMER
OFF is set
Temperature/Timer/Fan
speed display
Displays the set temperature
by default, or fan speed or
timer setting when using
TIMER ON/OFF functions
Temperature range:
16-30
o
C/60-86
O
F
Timer setting range:
0-24 hours
Fan speed setting range:
AU% -100%
ECO display
Displays when ECO
feature is activated
Battery display
Low battery detection
Remote LCD Screen Indicators
MODE display
Displays the current
mode, including:
11%-20%
1%-10%
21%-30%
91%-100%
AUTO
.................
This fan speed can not be
adjusted in AUTO or DRY
mode.
Note:
All indicators shown in the figure are for the purpose of clear presentation. But during the actual
operation only the relative functional signs are shown on the display window.
49
