Midea DC Fan Coil Unit
21
MKA-V850F
EWT
ΔT
Indoor temperature (D.B.)
16
18
20
22
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
TH
WF
WPD
[°C]
[°C]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
[kW]
[m^3/h]
[kPa]
40
5
4.36
0.76
40.09
3.91
0.68
33.27
3.47
0.6
27.01
3.03
0.52
21.34
8
3.79
0.41
14.11
3.34
0.36
11.37
2.89
0.31
8.88
2.44
0.26
6.64
10
3.39
0.29
8
2.93
0.25
6.24
2.46
0.21
4.65
1.97
0.17
3.14
12
2.94
0.21
4.65
2.45
0.18
3.36
1.9
0.14
1.7
1.39
0.99
0.95
15
1.68
0.99
0.9
1.55
0.1
0.89
1.42
0.99
0.89
1.28
0.99
0.87
45
5
5.47
0.95
58.35
5.03
0.87
50.31
4.58
0.8
42.81
4.14
0.72
35.87
8
4.93
0.53
21.6
4.48
0.49
18.34
4.04
0.44
15.31
3.59
0.39
12.52
10
4.55
0.39
12.89
4.1
0.36
10.79
3.65
0.32
8.84
3.2
0.28
7.05
12
4.16
0.3
8.12
3.7
0.27
6.66
3.24
0.23
5.31
2.76
0.2
4.07
15
3.5
0.2
4.19
3.01
0.17
3.23
2.48
0.14
2.09
1.73
0.99
0.86
50
5
6.58
1.15
79.13
6.14
1.07
69.95
5.69
0.99
61.29
5.25
0.91
53.15
8
6.05
0.66
30.18
5.61
0.61
26.42
5.16
0.56
22.89
4.72
0.51
19.58
10
5.69
0.49
18.5
5.24
0.46
16.06
4.8
0.42
13.78
4.35
0.38
11.64
12
5.32
0.38
12.08
4.87
0.35
10.38
4.42
0.32
8.79
3.97
0.29
7.31
15
4.73
0.27
6.8
4.27
0.25
5.71
3.8
0.22
4.7
3.33
0.19
3.75
55
5
7.69
1.34
102.26
7.25
1.26
91.99
6.8
1.18
82.23
6.35
1.11
72.98
8
7.17
0.78
39.77
6.73
0.73
35.54
6.28
0.68
31.53
5.83
0.63
27.74
10
6.82
0.59
24.79
6.37
0.55
22.03
5.93
0.52
19.42
5.48
0.48
16.96
12
6.46
0.47
16.52
6.01
0.44
14.59
5.57
0.4
12.77
5.12
0.37
11.05
15
5.91
0.34
9.7
5.45
0.32
8.46
5
0.29
7.29
4.54
0.26
6.19
60
5
8.8
1.54
127.62
8.35
1.46
116.31
7.91
1.38
105.5
7.46
1.3
95.18
8
8.29
0.9
50.31
7.84
0.85
45.64
7.39
0.81
41.17
6.95
0.76
36.92
10
7.94
0.69
31.71
7.49
0.65
28.65
7.05
0.61
25.74
6.6
0.58
22.97
12
7.59
0.55
21.42
7.15
0.52
19.27
6.7
0.49
17.22
6.25
0.45
15.28
15
7.06
0.41
12.9
6.61
0.38
11.51
6.16
0.36
10.19
5.71
0.33
8.95
65
5
9.91
1.73
155.14
9.46
1.66
142.82
9.01
1.58
130.99
8.56
1.5
119.64
8
9.4
1.03
61.76
8.95
0.98
56.66
8.5
0.93
51.76
8.06
0.88
47.06
10
9.06
0.79
39.23
8.61
0.75
35.89
8.15
0.67
32.6
7.72
0.67
29.62
12
8.72
0.63
26.75
8.27
0.6
24.39
7.82
0.57
22.13
7.37
0.54
19.98
15
8.2
0.48
16.38
7.75
0.45
14.85
7.3
0.42
13.39
6.85
0.4
12
Abbreviations:
Δt: Temperature Difference (℃)
TH: Total Heating Capacity (kW)
WF: Water Flow
(m
3
/h)
WPD: Water Pressure Drop (kPa)
