Midea MKG Series User Manual

AC Fan Coil Unit Two-pipe Wall-mounted Series
- 7 -
6.2 A type panel
MKG-250-C / MKG-300-C / MKG-400-C
Model MKG-250-C MKG-300-C MKG-400-C
Power supply V/Ph/Hz 220-240/1/50
Air flow (H/M/L)
m
3
/h 435/396/342 523/426/351 660/534/480
CFM 256/233/201 308/251/206 388/314/282
Cooling
Capacity (H/M/L) kW 1.94/1.84/1.68 2.64/2.4/1.99 2.94/2.58/2.34
Water flow rate(H/M/L) m
3
/h 0.35/0.33/0.3 0.47/0.43/0.36 0.53/0.46/0.42
Water pressure drop(H/M/L) kPa 31.6/28.6/25.2 37.5/30/24 57.2/47.6/38.7
Heating
Capacity (H/M/L) kW 2.34/2.15/1.94 2.9/2.6/2.22 3.46/2.75/2.52
Water flow rate(H/M/L) m
3
/h 0.43/0.39/0.35 0.53/0.47/0.4 0.63/0.5/0.46
Water pressure drop(H/M/L) kPa 35.2/34.9/30 39.3/31.5/25 70.8/55.1/46.2
Power input (H/M/L) W 35/32/31 47/43/39 50/51/47
Current Input A 0.11 0.17 0.18
Sound pressure level dB(A) 30/24/20 35/29/24 37/31/26
Fan motor
Type Low noise 3-speed fan motor
Quantity 1 1 1
Fan
Type Tangential fan
Quantity 1 1 1
Coil
Row 2 2 2
Diameter mm Φ7 Φ7 Φ7
Tube pitch(a)xrow pitch(b) mm 21×13.37 21×13.37 21×13.37
Dimension (W×H×D) mm 635×315×26.74 635×315×26.74 635×315×26.74
Fin spacing mm 1.5 1.5 1.5
Fin type Hydrophilic aluminium
Circuit 5 5 5
Max. working pressure MPa 1.6 1.6 1.6
Body
Net dimensions (W×H×D) mm 915×290×233 915×290×233 915×290×233
Packing size (W×H×D) mm 1020×390×315 1020×390×315 1020×390×315
Net weight kg 13 13 13.3
Gross weight kg 16.3 16.3 16.7
Pipe connections
Water inlet/outlet pipe inch G3/4 G3/4 G3/4
Drain pipe mm ODΦ20 ODΦ20 ODΦ20
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
