Midea MKG Series User Manual

AC Fan Coil Unit Two-pipe Wall-
mounted Series
- 8 -
MKG-500-C / MKG-600-C
Model MKG-500-C MKG-600-C
Power supply V/Ph/Hz 220-240/1/50
Air flow (H/M/L)
m3/h 841/723/594 915/836/714
CFM 495/425/349 538/492/420
Cooling
Capacity (H/M/L) kW 4.01/3.61/3.1 4.61/4.33/3.84
Water flow rate(H/M/L) m3/h 0.72/0.65/0.56 0.83/0.78/0.69
Water pressure drop(H/M/L) kPa 47.1/33.5/29.7 51/39.5/34
Heating
Capacity (H/M/L) kW 4.39/3.8/3.27 4.55/4.2/3.82
Water flow rate(H/M/L) m3/h 0.8/0.69/0.6 0.83/0.76/0.69
Water pressure drop(H/M/L) kPa 48.6/40.8/31.7 48/43/33
Power input (H/M/L) W 60/54/48 72/60/55
Current Input A 0.22 0.29
Sound pressure level dB(A) 39/33/28 40/34/29
Fan motor
Type Low noise 3-speed fan motor Low noise 3-speed fan motor
Quantity 1 1
Fan
Type Tangential fan Tangential fan
Quantity 1 1
Coil
Row 2 2
Diameter mm Φ7 Φ7
Tube pitch(a)xrow pitch(b) mm 21×13.37 21×13.37
Dimension (W×H×D) mm 785×315×26.74 785×315×26.74
Fin spacing mm 1.5 1.5
Fin type Hydrophilic aluminium Hydrophilic aluminium
Circuit 5 5
Max. working pressure MPa 1.6 1.6
Body
Net dimensions (W×H×D) mm 1072×315×237 1072×315×237
Packing size (W×H×D) mm 1180×415×315 1180×415×315
Net weight kg 15.8 15.8
Gross weight kg 19.4 19.4
Pipe connections
Water inlet/outlet pipe inch G3/4 G3/4
Drain pipe mm ODΦ20 ODΦ20
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
