Midea MKT3H-2200EG100

MCAC-KTSM-2012-03 High static pressure ducted
FCU
Specifications 5
6. Specifications
Model MKT3H-
800G70
800EG70
1000G70
1000EG70
1200G70
1200EG70
1400G70
1400EG70
Air flow
H/M/L
m
3
/h
1360/1220/1090
1700/1530/1380
2040/1880/1610
2380/2120/1860
H/M/L
CFM
800/720/640
1000/900/810
1200/1105/950
1400/1250/1095
External Static pressure
Pa
70
Cooling
Capacity
H/M/L
kW
6.6/6.37/6.12
8.8/8.19/7.57
10/9.44/8.53
12/11.47/10.24
Water flow rate
H
L/h
1135
1514
1720
2064
Water pressure drop
H
kPa
8
24
24
36
Heating
Capacity
H/M/L
kW
9.7/8.54/7.18
13.2/11.48/9.9
15/12.9/11.25
17.9/15.75/13.6
Water pressure drop
H
kPa
8.4
25
23.4
34.2
Power supply
V/Ph/Hz
220-240/1/50
Power input
H
W
320
350
350
350
Electric heater capacity ('E)
W
5000
5000
5000
5000
Sound pressure level
H/M/L
dB(A)
49/42/35
50/43/36
51/44/37
52/45/38
Fan motor
Type
Low noise 4-speed fan motor
Quantity
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
1
1
1
1
Coil
Row
2
3
3
4
Max. Working pressure
MPa
1.6
Diameter
mm
Φ9.52
Body
Dimensions (*/E)
W×H×D
mm
946×400×816 / 946×400×876
Net weight (*/E)
kg
50/53
52/55
52/55
54/57
Packing (*/E)
W×H×D
mm
1015×480×857 / 1015×480×925
Gross weight (*/E)
kg
55/58
57/60
57/60
59/62
Pipe
connection
Water inlet/outlet pipe
inch
RC3/4"
Drain pipe
mm
ODΦ32
Note:
1. H: high speed; M: medium speed; L: low speed
2. The data is the performance in 70Pa external static pressure.
3. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Entering air temperature 20°C, the same water flow as the cooling conditions.
4. Noise is tested in semi-anechoic test room.
5. * for models without EAH; E for models with EAH
