Midea MKT3H-2200G100 - Page 21

MCAC-KTSM-2012-03 High static pressure ducted FCU
Static Pressure Graph 21
MKT3H-2200(E)G100
Static pressure (Pa)
160
140
120
100
80
60
40
20
180
200
0
Low speed
Mid speed
High speed
Air volume(m3/h)
2400 2700
3000
3300
3600
3900
4200
4500
4800
5100 5400
2100
Super-high speed
