Midea MKT3H-2200G100

High static pressure ducted FCU MCAC-KTSM-2012-
03
6 Specifications
Specifications
Model MKT3H-
1600G100
1600EG100
1800G100
1800EG100
2200G100
2200EG100
Air flow
H/M/L
m
3
/h
2720/2450/2170
3060/2750/2450
3740/3360/2990
H/M/L
CFM
1600/1440/1280
1800/1620/1440
2200/1980/1760
External Static pressure
Pa
100
Cooling
Capacity
H/M/L
kW
14.1/13.03/11.87
15.8/14.6/13.46
19.9/18.58/17.24
Water flow rate
H
L/h
2425
2718
3423
Water pressure drop
H
kPa
60
78
110
Heating
Capacity
H/M/L
kW
21.2/18.23/15.69
23.8/20.94/17.85
30/26.7/22.5
Water pressure drop
H
kPa
57
74
105
Power supply
V/Ph/Hz
220-240/1/50
Power input
H
W
550
800
950
Electric heater capacity ('E)
W
9500
9500
9500
Sound pressure level
H/M/L
dB(A)
54/47/40
60/53/46
61/54/47
Fan motor
Type
Low noise 4-speed fan motor
Quantity
1
Fan
Type
Centrifugal, forward-curved Blades
Quantity
2
2
2
Coil
Row
3
3
3
Max. Working pressure
MPa
1.6
Diameter
mm
Φ9.52
Body
Dimensions (*/E)
W×H×D
mm
1290×400×809 / 1290×400×874
Net weight (*/E)
kg
76/82
Packing (*/E)
W×H×D
mm
1368×460×877 / 1368×460×950
Gross weight (*/E)
kg
83/89
Pipe
connection
Water inlet/outlet pipe
inch
RC3/4"
Drain pipe
mm
ODΦ32
Note:
1. H: high speed; M: medium speed; L: low speed
2. The data is the performance in 70Pa external static pressure.
3. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Entering air temperature 20°C, the same water flow as the cooling conditions.
4. Noise is tested in semi-anechoic test room.
5. * for models without EAH; E for models with EAH
