Service manual for Washing Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 39 －
4.5
Disassemble
the bracket
Disassemble four screw of bracket
Ten sleeve
4.6 Check the
clutch body
subassembly
No.10 Sleeve
4.7Check the
Motor
No.14 Sleeve
