2. General Specifications
Indoor model MUE-18HRFNX-QRD0 MUE-24HRFNX-QRD0 MUE-36HRFNX-QRD0
Outdoor model MOB30U-18HFN8-QRD0 MOCA30U-24HFN8-QRD0 MOD30U-36HFN8-QRD0
Power supply (Indoor ) V- Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Power Supply (Outdoor) V-Ph-Hz 220~240-1-50 220~240-1-50 220~240-1-50
Max. input consumption W 2200 2950 4700
Max. current A 10.0 13.5 21.5
Indoor fan motor
Model ZKFN-55-8-1 ZKFN-55-8-1 ZKFN-90-8-1
Qty 1 1 2
Insulation class E E E
IP rating IPX4 IPX4 IPX4
Input W 100.0 100.0 96.0
Capacitor uF / / /
Speed(Hi/Mi/Lo) r/min 950/850/750 1200/1080/890 1200/1050/850
Indoor coil
Number of rows 3.0 3.0 3
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37 21x13.37
Fin spacing mm 1.3 1.3 1.3
Fin type (code) Hydrophilic aluminum Hydrophilic aluminum Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube Φ7,Inner groove tube Φ7,Inner groove tube
Coil length x height x width mm 795x294x40.11 795x294x40.11 1300x294x40.11
Number of circuits 7 7 8
Indoor air flow (Hi/Mi/Lo) m3/h 902/786/677 1208/1066/853 2160/1844/1431
Indoor sound pressure level dB(A) 45/40/37 49/46/41 50/46/42
Indoor sound power level dB(A) 56 61 61
Indoor unit
Dimension(W*D*H) mm 1068x675x235 1068x675x235 1650x675x235
Packing (W*D*H) mm 1145x755x313 1145x755x313 1725x755x313
Net/Gross weight Kg 26.6/31.8 26.8/31.9 41.5/48
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25mm ODΦ25mm ODΦ25mm
Refrigerant piping Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.9(3/8"/5/8") Φ9.52/Φ15.9(3/8"/5/8")
Controller Remote contorl Remote contorl Remote contorl
Operation temperature °C 17-30 17-30 17-30
Room temperature
Cooling °C 17~32 17~32 17~32
Heating °C 0~30 0~30 0~30
Qty’per 20’ /40’ /40’HQ Indoor unit 102/220/252 102/220/252 72/147/167
Compressor
Model KSM135D23UFZ KTF235D22UMT KTF310D43UMT
Type ROTARY ROTARY ROTARY
Brand GMCC GMCC GMCC
Capacity W 4230 7650 10010
Input W 1080 2065 2765
Rated current(RLA) A 7.1 9.4 5.38
Refrigerant oil/oil charge ml VG74/450 RB74A F/670 VG74/1000
Outdoor fan motor
Model ZKFN-40-8-1L ZKFN-50-8-2 ZKFN-120-8-2
Qty 1 1 1
Insulation class E E E
IP rating IPX4 IPX0 IPX4
Output W 63.0 115.0 150.0
Capacitor uF / / /
Speed r/min 810 850 1050
