REMOVE PERFECTCHILL FLEX DRAWER
1. Pull out the exterior drawer to its full extension.
2. Using both hands, grasp the left-hand and right-hand sides of the inner
drawer tray.
3. Lift up on the front end of the tray.
4. Pull the tray slightly toward you to disengage the slots from the hooks
on the slide rails.
a
a
Slide rail hook
5. Once the tray is disengaged, push it slightly back into the opening until
the edge clears the outer drawer lip, and then lift the tray up and out.
6. Using a Phillips screwdriver, remove the screw fastening the wiring
cover to the interior of the drawer front.
a b
a
Wiring cover
b Wiring cover
screw
7. Push upward on the bottom edge of the wiring cover until the cover
slot clears the clasp, and then pull the cover away from the drawer
front.
