Midea MRS26D5AST User Manual

13
Refrigerator
Safety
Operating
Requirements
Parts and
Features
Installation
Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
6. Using an 8 mm socket wrench, remove the three hinge screws.
7. Using a Phillips screwdriver, remove the ground screw (left freezer door ).
Hinge screws
Ground screw
Top hinge
NOTE: Provide additional support for the door while the hinge is being
removed. Do not depend on the door gasket magnets to hold the door
in place while you are working.
8. Remove the top left freezer door hinge.
9. Using both hands, slowly swing the door until it is open to a 90° angle
door onto a soft surface to protect the finish.
10.
Repeat this procedure to remove the right refrigerator door.
REPLACE DOORS
NOTE: The hinge pin extends from the bottom edge of the door.
1. Insert the hinge pin into the opening in the bottom hinge.
2. Insert the top hinge into the top of the door.
3. Using the hinge screws removed earlier, fasten the top hinge to the top
of the cabinet.
4. Replace the ground screw (left door).
5. Reconnect the water tube.
6. Replace the left door following steps 1 through 3.
7. Using the four screws removed earlier, fasten the hinge cover to the
top of the cabinet.
90°

Midea MRS26D5AST Specifications

General

Style	Side-by-Side
Color	Stainless Steel
Number of Doors	2
Total Capacity	29.5 Cu. Ft.
Refrigerator Capacity	450 L
Freezer Capacity	250 L
Number of Refrigerator Shelves	5: Adjustable
Number of Refrigerator Bins	1 small) and Dairy Corner
Humidity Controlled Crispers	1
Number of Freezer Shelves/Baskets	-
Refrigerator Temperature	34/44 °F
Refrigerator Special Features	Internal Water Dispenser
Freezer Special Features	Power Freeze Option
Defrost System	Automatic
Noise level	43 dB
Refrigerant	-
Energy Class	-
Annual Energy Consumption	715 kWh
Voltage	115 V
Frequency	60Hz
Current	-

Weight and Dimensions

Depth	742 mm
Height	70 1/8 in
Width	1000 mm
Net Weight	-
