Midea MS11M-09HRN1 - 3 Specification

Oasis On-off DM12-01.01.09en
8 Service manual
3. Specification
Indoor
MS11M-09HRN1 MS11M-12HRN1
Outdoor
MO11M-09HN1 MO11M-12HN1
Powersupply Ph‐V‐Hz
220-240V~ 50Hz, 1Ph 220-240V~ 50Hz, 1Ph
Cooling
Capacity
Btu/h
9000 12000
kW
2,64 3,52
Input W
820 1090
Ratedcurrent A
3.5 4.7
EER W/W
3.22 3.23
Heating
Capacity
Btu/h
9500 12500
kW
2,78 3,66
Input W
770 1010
Ratedcurrent A
3.35 4.4
COP W/W
3.62 3.62
MoistureRemoval L/h
1.0 1.2
Max.inputconsumption W
1300 1800
Max.current A
6.0 8.0
Startingcurrent A
21.7 20.1
Compressor
Model 
PA103M1C-4DZDE2 PA135G1C-4FTL
Type 
ROTARY ROTARY
Brand 
GMCC GMCC
Capacity Btu/h
8428/8530 11191/11362
Input W
830/860 1075/1100
Ratedcurrent(RLA) A
3.85/3.73 5.37/5.39
LockedrotorAmp(LRA) A
21.7 20.1
Thermalprotector 
B160-135-241E ----
Thermalprotectorposition 
EXTERNAL INTERNAL
Capacitor uF
25 35
Refrigerantoil/oilcharge ml
ESTER OIL VG74 350cc ESTER OIL VG74/400
Indoorfanmotor
Model 
RPG13H RPG20D
Brand 
Welling Welling
Input W
34 43.3
Capacitor
uF
1.2 1.5
Speed(Hi/Mi/Lo) r/min
1200/1000/700 1220/1000/800
Indoorcoil
a.Numberofrows 
2 2
b.Tubepitch(a)xrowpitch(b) mm
21x13.37 21x13.37
c.Finspacing mm
1.3 1.3
d.Fintype(code) 
Hydrophilic aluminium Hydrophilic aluminium
e.Tubeoutsidedia.andtype mm
7, innergroove tube 7,innergroove tube
f.Coillengthxheightxwidth mm
580x252x26.74 665x315x26.74
g.Numberofcircuits 
2 3
Indoorairflow(Hi/Mi/Lo) m
3
/h
550/450/320 700/570/460
Indoornoiselevel(Hi/Mi/Lo) dB(A)
41/37/29 43/39/32
Indoorunit Dimension(W*D*H) mm
750x198x280 835x198x280
