V6R VRF 50/60Hz
12
Midea V6R Series Engineering Data Book
4.2 Heat Recovery Ventilator
HRV - D 200
○
1
○
2
○
3
Legend
No. Code Remarks
1 HRV Heatrecoveryventilator
2 D Seriescategory(D:DCseries)
3 200 Airflowinm
3
/h
4.3 High Temperature Hydro Module
SMK - D 140 H H N1-3
○
1
○
2
○
3
○
4
○
5
○
6
Legend
No. Code Remarks
1 SMK Mideahydromodule
2 D UsedforVRFsystem
3 140 Capacityindex(thecapacityinkWmultipliedby10)
4 H Hightemperaturetype
5 H
Powersupply
Omit:1phase,220‐240V,50Hz
H:1phase,220‐240V,50/60Hz
6 N1‐3 Refrigeranttype(R410A&R134a)
4.4 Outdoor Units
M V6 - R 280 W V2 G N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
⑧
Legend
No. Code Remarks
1 M Midea
2 V6 The6
th
generationVRF
3 R Heatrecovery
4 280 Capacityindex(thecapacityinkWmultipliedby10)
5 W Unitcategory(W:VRFoutdoorunit)
6 V2 Type(V2:AllDCinverter)
7 G Powersupply(G:3phase,380‐415V,50/60Hz)
8 N1 Refrigeranttype(N1:R410A)
To Next Page
