Midea MV6-R450WV2GN1 User Manual

V6R VRF 50/60Hz
111
Part 2
-
Outdoor Unit Engineering Data
10 Operating Limits
Figure 2-10.1: Cooling operating limits
Figure 2-10.2: DHW operating limits
Figure 2-10.3: Heating operating limits
Notes:
1. These figures assume the following operating conditions:
 Equivalent piping length: 7.5m
 Level difference: 0
50
55
45
40
35
30
25
20
Outdoor temperature (
o
C DB)
Range for cooling operation
Indoor temperature (
o
C WB)
15
10
5
0
-5
-10
10 15 20 25 30
-15
-20
Low temp.
operation range
for MS01
45
40
35
30
25
20
Outdoor temperature (
o
C DB)
Range for DHW operation
Indoor temperature (
o
C WB)
15
10
5
0
-5
-10
10 15 20 25 30
-15
-20
-25
Cooling IDU
required
DHW operation
range
Outdoor
tempe
rature (
o
C WB)
Range for continuous heating operation
25
20
15
10
5
0
-10
-15
-20
-25
-30
Indoor temperature (
o
C DB)
10 15 20 25 30 35
-5
