Midea VC Pro Series Engineering Data Book
Table 2-8.21: 24HP cooling part load performance
Part
load
Outdoor
temperature (°C
DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
100%
-5
45.23
6.49
53.84
7.82
62.69
9.31
67.00
9.97
71.31
10.82
80.16
12.33
84.71
12.86
-2
45.23
6.57
53.84
7.92
62.69
9.41
67.00
10.15
71.31
10.96
80.16
12.47
84.71
12.95
0
45.23
6.64
53.84
8.00
62.69
9.51
67.00
10.28
71.31
11.06
80.16
12.68
84.71
13.09
2
45.23
6.77
53.84
8.11
62.69
9.62
67.00
10.41
71.31
11.19
80.16
12.86
84.71
13.30
4
45.23
6.82
53.84
8.19
62.69
9.76
67.00
10.57
71.31
11.33
80.16
12.99
84.71
13.44
6
45.23
6.92
53.84
8.35
62.69
9.89
67.00
10.75
71.31
11.50
80.16
13.17
84.71
13.65
8
45.23
7.05
53.84
8.48
62.69
10.07
67.00
10.88
71.31
11.68
80.16
13.38
84.71
13.88
10
45.23
7.13
53.84
8.64
62.69
10.23
67.00
11.06
71.31
11.90
80.16
13.60
84.71
14.07
12
45.23
7.25
53.84
8.81
62.69
10.42
67.00
11.26
71.31
12.12
80.16
13.85
83.51
14.18
14
45.23
7.38
53.84
8.98
62.69
10.62
67.00
11.48
71.31
12.35
80.16
14.13
82.55
14.36
16
45.23
7.53
53.84
9.14
62.69
10.84
67.00
11.70
71.31
12.60
79.68
14.30
81.36
14.52
18
45.23
7.66
53.84
9.31
62.69
11.04
67.00
11.93
71.31
12.85
78.73
14.77
80.40
14.88
20
45.23
7.80
53.84
9.50
62.69
11.37
67.00
12.54
71.31
13.77
77.53
15.47
79.20
15.61
21
45.23
7.89
53.84
9.59
62.69
11.79
67.00
12.99
71.31
14.24
77.05
15.83
78.73
15.97
23
45.23
8.08
53.84
10.23
62.69
12.63
67.00
13.91
71.31
15.27
76.09
16.55
77.53
16.69
25
45.23
8.61
53.84
10.93
62.69
13.52
67.00
14.91
71.31
16.36
74.90
17.28
76.57
17.42
27
45.23
9.20
53.84
11.65
62.69
14.44
67.00
15.94
71.31
17.50
73.70
18.00
75.38
18.17
29
45.23
9.78
53.84
12.43
62.69
15.41
67.00
17.03
71.07
18.59
72.74
18.76
74.42
18.90
31
45.23
10.42
53.84
13.27
62.69
16.44
67.00
18.17
70.11
19.32
71.55
19.48
73.22
19.65
33
45.23
11.06
53.84
14.13
62.69
17.53
67.00
19.40
68.92
20.04
70.59
20.21
72.27
20.40
35
45.23
11.76
53.84
15.02
62.69
18.70
67.00
20.68
67.72
20.76
69.39
20.96
71.07
21.13
37
45.23
12.51
53.84
16.00
62.69
19.93
65.79
21.40
66.76
21.52
68.43
21.71
69.87
21.88
39
45.23
13.29
53.84
17.00
62.69
21.21
64.84
22.13
65.56
22.24
67.24
22.44
68.92
22.66
41
45.23
13.91
53.84
17.62
62.69
21.98
63.84
22.28
65.06
22.58
66.07
22.96
67.91
23.12
43
45.23
14.53
53.84
18.24
62.69
22.39
62.83
22.54
64.59
22.80
66.46
23.11
66.71
23.38
46
45.23
15.36
53.84
19.07
62.69
22.77
61.49
22.85
64.25
23.21
65.90
23.47
65.37
23.69
48
45.23
16.04
53.84
19.74
62.69
22.81
58.96
23.11
64.15
23.63
61.88
23.71
63.94
23.91
50
44.69
16.13
53.20
19.83
61.98
22.91
58.49
23.22
63.52
23.72
61.17
23.84
63.25
24.03
52
44.15
16.17
52.39
19.91
61.17
23.00
57.42
23.31
62.51
23.84
60.37
23.93
62.51
24.11
55
43.35
16.28
51.59
20.06
60.10
23.18
56.62
23.49
61.71
23.99
59.30
24.07
61.44
24.30
75%
-5
33.98
4.43
40.67
5.19
47.11
5.88
50.45
6.31
53.80
6.73
60.23
7.70
66.92
8.85
-2
33.98
4.46
40.67
5.21
47.11
5.92
50.45
6.43
53.80
6.85
60.23
7.82
66.92
8.97
0
33.98
4.49
40.67
5.29
47.11
6.04
50.45
6.55
53.80
6.97
60.23
7.98
66.92
9.10
2
33.98
4.51
40.67
5.31
47.11
6.14
50.45
6.67
53.80
7.09
60.23
8.15
66.92
9.24
4
33.98
4.57
40.67
5.44
47.11
6.27
50.45
6.79
53.80
7.25
60.23
8.28
66.92
9.46
6
33.98
4.64
40.67
5.54
47.11
6.43
50.45
7.01
53.80
7.42
60.23
8.43
66.92
9.64
8
33.98
4.73
40.67
5.70
47.11
6.57
50.45
7.12
53.80
7.58
60.23
8.67
66.92
9.82
10
33.98
4.83
40.67
5.79
47.11
6.75
50.45
7.27
53.80
7.78
60.23
8.85
66.92
9.94
12
33.98
4.94
40.67
5.87
47.11
6.88
50.45
7.40
53.80
7.92
60.23
9.01
66.92
10.13
14
33.98
5.03
40.67
5.98
47.11
6.99
50.45
7.51
53.80
8.06
60.23
9.18
66.92
10.32
16
33.98
5.11
40.67
6.09
47.11
7.13
50.45
7.68
53.80
8.22
60.23
9.34
66.92
10.52
18
33.98
5.19
40.67
6.20
47.11
7.27
50.45
7.81
53.80
8.36
60.23
9.53
66.92
10.73
20
33.98
5.27
40.67
6.31
47.11
7.40
50.45
7.95
53.80
8.52
60.23
9.72
66.92
11.03
21
33.98
5.33
40.67
6.36
47.11
7.46
50.45
8.03
53.80
8.60
60.23
9.86
66.92
11.42
23
33.98
5.41
40.67
6.47
47.11
7.62
50.45
8.30
53.80
9.04
60.23
10.57
66.92
12.24
25
33.98
5.52
40.67
6.75
47.11
8.11
50.45
8.88
53.80
9.64
60.23
11.31
66.92
13.08
27
33.98
5.85
40.67
7.18
47.11
8.66
50.45
9.45
53.80
10.30
60.23
12.07
66.92
13.98
29
33.98
6.20
40.67
7.62
47.11
9.20
50.45
10.08
53.80
10.95
60.23
12.86
66.92
14.94
31
33.98
6.55
40.67
8.08
47.11
9.81
50.45
10.71
53.80
11.66
60.23
13.71
66.92
15.92
33
33.98
6.96
40.67
8.60
47.11
10.43
50.45
11.39
53.80
12.43
60.23
14.61
66.92
16.99
35
33.98
7.37
40.67
9.12
47.11
11.06
50.45
12.13
53.80
13.22
60.23
15.57
66.92
18.11
37
33.98
7.78
40.67
9.67
47.11
11.77
50.45
12.86
53.80
14.07
60.23
16.58
66.92
19.28
39
33.98
8.25
40.67
10.24
47.11
12.48
50.45
13.68
53.80
14.94
60.23
17.62
66.92
20.54
41
33.98
8.61
40.67
10.61
47.11
12.85
50.45
14.14
53.80
15.39
60.23
18.34
66.92
21.45
43
33.98
9.31
40.67
11.33
47.11
13.37
50.45
14.90
53.80
15.85
60.23
19.01
66.92
22.12
46
33.98
9.52
40.67
11.58
47.11
13.66
50.45
15.14
53.80
16.64
60.23
20.04
66.92
22.96
48
33.98
9.70
40.67
11.64
47.11
13.82
50.45
15.40
53.80
17.10
60.23
20.98
66.92
23.53
50
33.75
9.83
40.31
11.76
46.62
13.87
50.05
15.46
53.18
17.16
59.48
21.06
66.34
23.64
52
33.20
9.87
39.76
11.80
46.06
13.91
49.19
15.53
52.32
17.24
58.62
21.14
65.23
23.71
55
32.59
9.91
38.90
11.87
45.20
14.03
48.33
15.62
51.46
17.35
57.77
21.28
64.38
23.89
Abbreviations:
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Table continued on next page …
