Midea VC Pro Series Engineering Data Book
Table 2-8.12: 30HP cooling capacity (continued)
Combination
(%)
(Capacity
index)
Outdoor
temperature
(°C DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
90%
-5
51.61
8.19
61.63
9.83
71.64
11.60
76.50
12.66
81.36
13.46
91.37
15.48
101.39
17.73
-2
51.61
8.27
61.63
9.93
71.64
11.75
76.50
12.83
81.36
13.63
91.37
15.63
101.39
17.90
0
51.61
8.40
61.63
10.06
71.64
11.93
76.50
12.98
81.36
13.80
91.37
15.81
101.39
18.04
2
51.61
8.52
61.63
10.19
71.64
12.05
76.50
13.19
81.36
14.02
91.37
16.14
101.39
18.30
4
51.61
8.65
61.63
10.34
71.64
12.25
76.50
13.36
81.36
14.20
91.37
16.39
101.39
18.57
6
51.61
8.77
61.63
10.54
71.64
12.48
76.50
13.62
81.36
14.44
91.37
16.64
101.39
18.88
8
51.61
8.94
61.63
10.74
71.64
12.74
76.50
13.79
81.36
14.70
91.37
16.95
101.39
19.06
10
51.61
9.11
61.63
10.98
71.64
12.96
76.50
14.00
81.36
15.03
91.37
17.17
101.39
19.37
12
51.61
9.27
61.63
11.17
71.64
13.20
76.50
14.23
81.36
15.31
91.37
17.50
101.39
19.72
14
51.61
9.42
61.63
11.37
71.64
13.44
76.50
14.52
81.36
15.59
91.37
17.82
101.39
20.08
16
51.61
9.58
61.63
11.57
71.64
13.72
76.50
14.80
81.36
15.91
91.37
18.17
101.09
20.44
18
51.61
9.74
61.63
11.81
71.64
13.96
76.50
15.07
81.36
16.22
91.37
18.53
99.88
21.08
20
51.61
9.94
61.63
12.08
71.64
14.24
76.50
15.39
81.36
16.82
91.37
19.92
98.36
22.07
21
51.61
10.02
61.63
12.17
71.64
14.47
76.50
15.91
81.36
17.42
91.37
20.64
97.75
22.59
23
51.61
10.22
61.63
12.65
71.64
15.51
76.50
17.06
81.36
18.69
91.37
22.15
96.23
23.62
25
51.61
10.78
61.63
13.52
71.64
16.58
76.50
18.25
81.36
19.96
91.37
23.70
95.02
24.66
27
51.61
11.45
61.63
14.40
71.64
17.70
76.50
19.49
81.36
21.36
91.37
25.37
93.50
25.69
29
51.61
12.21
61.63
15.35
71.64
18.89
76.50
20.80
81.36
22.83
90.46
26.53
92.28
26.72
31
51.61
12.96
61.63
16.35
71.64
20.12
76.50
22.19
81.36
24.34
88.95
27.56
90.77
27.80
33
51.61
13.76
61.63
17.38
71.64
21.47
76.50
23.66
81.36
25.97
87.73
28.63
89.55
28.83
35
51.61
14.63
61.63
18.49
71.64
22.87
76.50
25.21
81.36
27.68
86.22
29.67
88.04
29.91
37
51.61
15.51
61.63
19.65
71.64
24.34
76.50
26.84
81.36
29.51
84.69
30.70
86.82
30.94
39
51.61
16.46
61.63
20.92
71.64
25.89
76.50
28.59
81.36
31.42
83.48
31.78
85.31
32.01
41
51.61
17.03
61.63
21.87
71.64
26.83
76.50
29.35
81.36
31.61
82.90
32.58
84.73
32.77
43
50.71
17.53
60.55
22.40
70.39
27.28
75.17
29.56
79.94
31.70
81.04
32.41
82.54
32.68
46
50.71
18.64
60.55
23.51
70.39
28.39
75.17
30.55
79.94
32.58
80.59
32.75
81.27
33.11
48
50.71
19.68
60.55
24.60
70.39
29.46
75.17
30.94
79.94
32.86
79.91
33.21
79.08
33.56
50
50.06
19.78
59.98
24.71
69.60
29.63
74.57
31.09
79.23
33.03
79.23
33.35
78.25
33.74
52
49.38
19.83
59.01
24.81
68.63
29.73
73.21
31.19
77.87
33.15
77.87
33.52
77.20
33.84
55
48.71
20.00
58.03
24.98
67.57
29.96
72.23
31.47
76.59
33.40
76.59
33.74
75.92
34.12
80%
-5
45.84
7.22
54.64
8.54
63.44
10.11
68.00
10.75
72.56
11.57
81.36
13.38
90.16
15.27
-2
45.84
7.33
54.64
8.64
63.44
10.19
68.00
10.92
72.56
11.68
81.36
13.51
90.16
15.42
0
45.84
7.45
54.64
8.75
63.44
10.32
68.00
11.04
72.56
11.89
81.36
13.70
90.16
15.63
2
45.84
7.60
54.64
8.88
63.44
10.47
68.00
11.26
72.56
12.11
81.36
13.97
90.16
15.93
4
45.84
7.73
54.64
9.03
63.44
10.67
68.00
11.51
72.56
12.32
81.36
14.23
90.16
16.14
6
45.84
7.86
54.64
9.24
63.44
10.83
68.00
11.77
72.56
12.55
81.36
14.44
90.16
16.42
8
45.84
8.01
54.64
9.45
63.44
11.09
68.00
11.96
72.56
12.83
81.36
14.65
90.16
16.74
10
45.84
8.07
54.64
9.67
63.44
11.38
68.00
12.25
72.56
13.13
81.36
14.99
90.16
16.90
12
45.84
8.19
54.64
9.82
63.44
11.57
68.00
12.49
72.56
13.40
81.36
15.27
90.16
17.22
14
45.84
8.35
54.64
10.02
63.44
11.77
68.00
12.69
72.56
13.64
81.36
15.55
90.16
17.54
16
45.84
8.47
54.64
10.18
63.44
12.01
68.00
12.93
72.56
13.88
81.36
15.87
90.16
17.86
18
45.84
8.63
54.64
10.38
63.44
12.25
68.00
13.20
72.56
14.16
81.36
16.19
90.16
18.22
20
45.84
8.79
54.64
10.58
63.44
12.49
68.00
13.44
72.56
14.44
81.36
16.78
90.16
19.49
21
45.84
8.87
54.64
10.66
63.44
12.61
68.00
13.60
72.56
14.76
81.36
17.38
90.16
20.20
23
45.84
9.03
54.64
10.90
63.44
13.20
68.00
14.48
72.56
15.79
81.36
18.61
90.16
21.68
25
45.84
9.31
54.64
11.57
63.44
14.12
68.00
15.47
72.56
16.86
81.36
19.93
90.16
23.19
27
45.84
9.90
54.64
12.33
63.44
15.03
68.00
16.51
72.56
18.02
81.36
21.28
90.16
24.82
29
45.84
10.54
54.64
13.13
63.44
16.03
68.00
17.58
72.56
19.25
81.36
22.71
90.16
26.53
31
45.84
11.18
54.64
13.96
63.44
17.06
68.00
18.73
72.56
20.52
81.36
24.26
88.64
27.56
33
45.84
11.89
54.64
14.83
63.44
18.18
68.00
19.97
72.56
21.84
81.36
25.85
87.43
28.60
35
45.84
12.61
54.64
15.79
63.44
19.33
68.00
21.24
72.56
23.27
81.36
27.56
85.91
29.63
37
45.84
13.36
54.64
16.74
63.44
20.56
68.00
22.63
72.56
24.78
81.36
29.39
84.69
30.66
39
45.84
14.16
54.64
17.86
63.44
21.88
68.00
24.06
72.56
26.37
81.36
31.30
83.18
31.74
41
45.84
14.48
54.64
18.02
63.44
22.19
68.00
24.70
72.56
26.85
81.36
32.10
82.67
32.30
43
45.04
14.63
53.69
17.85
62.34
22.11
66.81
24.67
71.29
26.73
79.94
31.88
80.73
32.05
46
45.04
15.05
53.69
18.06
62.34
22.53
66.81
25.19
71.29
27.19
79.94
32.23
79.72
32.58
48
45.04
15.54
53.69
18.16
62.34
22.88
66.81
25.53
71.29
27.40
79.94
32.53
79.05
32.99
50
44.77
15.62
53.05
18.27
61.67
22.98
66.28
25.67
70.62
27.57
79.24
32.70
78.25
33.20
52
44.10
15.68
52.38
18.33
60.67
23.09
65.28
25.73
69.62
27.67
77.91
32.82
77.24
33.30
55
43.10
15.79
51.38
18.50
59.67
23.25
63.94
25.94
68.28
27.84
76.57
33.07
75.91
33.57
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
