Part 2 - Outdoor Unit Engineering Data
Table 2-8.5: 16HP cooling capacity (continued)
Combination
(%)
(Capacity
index)
Outdoor
temperature
(°C DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
50%
-5
15.19
1.98
18.16
2.29
21.05
2.64
22.50
2.76
23.95
2.91
26.84
3.31
29.89
3.57
-2
15.19
2.00
18.16
2.34
21.05
2.66
22.50
2.80
23.95
2.96
26.84
3.35
29.89
3.62
0
15.19
2.03
18.16
2.38
21.05
2.71
22.50
2.84
23.95
3.00
26.84
3.41
29.89
3.68
2
15.19
2.06
18.16
2.41
21.05
2.76
22.50
2.88
23.95
3.05
26.84
3.43
29.89
3.75
4
15.19
2.08
18.16
2.45
21.05
2.79
22.50
2.91
23.95
3.11
26.84
3.51
29.89
3.85
6
15.19
2.12
18.16
2.49
21.05
2.83
22.50
2.98
23.95
3.17
26.84
3.57
29.89
3.96
8
15.19
2.17
18.16
2.53
21.05
2.88
22.50
3.05
23.95
3.21
26.84
3.62
29.89
4.09
10
15.19
2.21
18.16
2.56
21.05
2.92
22.50
3.09
23.95
3.30
26.84
3.72
29.89
4.15
12
15.19
2.23
18.16
2.59
21.05
2.97
22.50
3.16
23.95
3.37
26.84
3.78
29.89
4.21
14
15.19
2.26
18.16
2.63
21.05
3.01
22.50
3.22
23.95
3.42
26.84
3.85
29.89
4.30
16
15.19
2.30
18.16
2.66
21.05
3.06
22.50
3.27
23.95
3.47
26.84
3.92
29.89
4.36
18
15.19
2.33
18.16
2.71
21.05
3.11
22.50
3.32
23.95
3.54
26.84
3.98
29.89
4.44
20
15.19
2.36
18.16
2.74
21.05
3.16
22.50
3.37
23.95
3.60
26.84
4.05
29.89
4.53
21
15.19
2.38
18.16
2.78
21.05
3.19
22.50
3.40
23.95
3.63
26.84
4.10
29.89
4.58
23
15.19
2.41
18.16
2.81
21.05
3.24
22.50
3.47
23.95
3.70
26.84
4.16
29.89
4.68
25
15.19
2.45
18.16
2.86
21.05
3.30
22.50
3.54
23.95
3.82
26.84
4.38
29.89
4.99
27
15.19
2.49
18.16
2.97
21.05
3.49
22.50
3.77
23.95
4.05
26.84
4.66
29.89
5.32
29
15.19
2.63
18.16
3.14
21.05
3.70
22.50
4.00
23.95
4.31
26.84
4.96
29.89
5.67
31
15.19
2.78
18.16
3.32
21.05
3.92
22.50
4.25
23.95
4.58
26.84
5.27
29.89
6.03
33
15.19
2.94
18.16
3.52
21.05
4.16
22.50
4.49
23.95
4.86
26.84
5.60
29.89
6.41
35
15.19
3.11
18.16
3.72
21.05
4.39
22.50
4.76
23.95
5.14
26.84
5.95
29.89
6.81
37
15.19
3.27
18.16
3.93
21.05
4.66
22.50
5.04
23.95
5.45
26.84
6.31
29.89
7.24
39
15.19
3.45
18.16
4.15
21.05
4.92
22.50
5.34
23.95
5.78
26.84
6.69
29.89
7.68
41
15.19
3.60
18.16
4.33
21.05
5.10
22.50
5.59
23.95
6.03
26.84
7.05
29.89
8.04
43
14.92
3.76
17.84
4.54
20.69
5.18
22.11
5.73
23.53
6.07
26.37
7.27
29.37
8.24
46
14.92
3.85
17.84
4.66
20.69
5.53
22.11
6.17
23.53
6.33
26.37
7.97
29.37
8.95
48
14.92
3.92
17.84
4.77
20.69
5.84
22.11
6.59
23.53
6.63
26.37
8.60
29.37
9.62
50
14.75
3.95
17.73
4.81
20.54
5.88
21.93
6.60
23.35
6.65
26.15
8.65
29.12
9.68
52
14.57
3.98
17.38
4.83
20.18
5.91
21.58
6.62
22.99
6.67
25.80
8.69
28.61
9.70
55
14.39
4.00
17.20
4.87
19.83
5.95
21.22
6.67
22.64
6.71
25.27
8.76
28.25
9.77
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
