Part 2 - Outdoor Unit Engineering Data
Table 2-8.8: 22HP cooling capacity (continued)
Combination
(%)
(Capacity
index)
Outdoor
temperature
(°C DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
110%
-5
45.60
6.97
54.37
8.68
63.13
10.36
67.52
11.12
71.90
11.96
77.39
12.42
79.14
12.81
-2
45.60
7.11
54.37
8.79
63.13
10.45
67.52
11.23
71.90
12.06
77.39
12.55
79.14
12.88
0
45.60
7.18
54.37
8.84
63.13
10.52
67.52
11.30
71.90
12.19
77.39
12.67
79.14
13.03
2
45.60
7.33
54.37
8.93
63.13
10.69
67.52
11.42
71.90
12.32
77.39
12.85
79.14
13.19
4
45.60
7.48
54.37
9.03
63.13
10.79
67.52
11.57
71.90
12.51
77.39
13.03
79.14
13.32
6
45.60
7.55
54.37
9.13
63.13
10.90
67.52
11.75
71.90
12.65
77.39
13.17
79.14
13.52
8
45.60
7.62
54.37
9.28
63.13
11.02
67.52
11.87
71.90
12.79
77.39
13.26
79.14
13.66
10
45.60
7.71
54.37
9.40
63.13
11.18
67.52
12.07
71.90
13.00
77.39
13.35
79.14
13.78
12
45.60
7.88
54.37
9.59
63.13
11.39
67.52
12.32
71.90
13.25
76.51
13.55
78.04
13.96
14
45.60
8.01
54.37
9.76
63.13
11.61
67.52
12.54
71.90
13.49
75.41
13.66
77.17
14.06
16
45.60
8.15
54.37
9.95
63.13
11.83
67.52
12.78
71.90
13.76
74.54
13.82
76.07
14.21
18
45.60
8.31
54.37
10.14
63.13
12.07
67.52
13.14
71.90
14.42
73.44
14.53
75.19
14.66
20
45.60
8.48
54.37
10.36
63.13
12.78
67.52
14.12
70.81
15.13
72.56
15.24
74.10
15.37
21
45.60
8.56
54.37
10.66
63.13
13.25
67.52
14.64
70.37
15.48
71.91
15.59
73.66
15.73
23
45.60
8.97
54.37
11.42
63.13
14.20
67.52
15.70
69.28
16.16
71.03
16.32
72.56
16.46
25
45.60
9.57
54.37
12.21
63.13
15.18
67.52
16.82
68.39
16.87
69.93
17.04
71.68
17.17
27
45.60
10.20
54.37
13.06
63.13
16.25
66.43
17.53
67.30
17.58
69.06
17.75
70.59
17.91
29
45.60
10.88
54.37
13.93
63.13
17.36
65.55
18.24
66.43
18.32
67.96
18.48
69.71
18.65
31
45.60
11.58
54.37
14.86
63.13
18.54
64.45
18.94
65.33
19.03
67.08
19.19
68.61
19.38
33
45.60
12.32
54.37
15.84
62.70
19.54
63.57
19.65
64.45
19.73
65.98
19.93
67.74
20.12
35
45.60
13.11
54.37
16.87
61.60
20.25
62.48
20.36
63.35
20.47
64.89
20.66
66.65
20.85
37
45.60
13.96
54.37
17.96
60.72
20.99
61.60
21.07
62.26
21.18
64.01
21.40
65.55
21.59
39
45.60
14.83
54.37
19.14
59.63
21.70
60.50
21.81
61.38
21.92
62.92
22.13
64.67
22.35
41
45.60
14.98
54.37
19.29
59.16
21.85
60.03
21.96
60.92
22.07
62.12
22.29
62.72
22.50
43
44.89
14.86
53.53
19.19
57.78
21.61
58.64
21.72
59.51
21.82
60.61
21.97
60.80
22.55
46
44.89
15.34
53.53
19.29
57.20
21.81
58.03
21.98
58.98
22.02
59.99
22.57
60.24
23.08
48
44.89
15.85
53.53
20.89
56.37
21.91
57.11
22.09
58.31
22.22
59.01
22.60
59.46
23.27
50
44.35
15.98
53.02
21.06
55.85
22.06
56.59
22.24
57.82
22.38
58.50
22.76
58.74
23.46
52
43.86
16.02
52.28
21.12
54.93
22.16
55.60
22.34
56.83
22.46
57.57
22.86
58.00
23.54
55
43.18
16.12
51.30
21.28
54.19
22.32
54.93
22.50
55.85
22.60
56.59
23.02
57.08
23.68
100%
-5
41.51
6.35
49.42
7.65
57.55
9.10
61.50
9.75
65.45
10.58
73.58
12.06
77.75
12.58
-2
41.51
6.43
49.42
7.75
57.55
9.20
61.50
9.93
65.45
10.72
73.58
12.20
77.75
12.66
0
41.51
6.49
49.42
7.83
57.55
9.31
61.50
10.05
65.45
10.82
73.58
12.40
77.75
12.81
2
41.51
6.62
49.42
7.94
57.55
9.41
61.50
10.19
65.45
10.94
73.58
12.58
77.75
13.01
4
41.51
6.67
49.42
8.01
57.55
9.55
61.50
10.34
65.45
11.09
73.58
12.70
77.75
13.15
6
41.51
6.77
49.42
8.17
57.55
9.67
61.50
10.52
65.45
11.25
73.58
12.89
77.75
13.35
8
41.51
6.90
49.42
8.29
57.55
9.85
61.50
10.64
65.45
11.43
73.58
13.09
77.75
13.57
10
41.51
6.98
49.42
8.45
57.55
10.01
61.50
10.82
65.45
11.64
73.58
13.31
77.75
13.77
12
41.51
7.09
49.42
8.62
57.55
10.20
61.50
11.02
65.45
11.86
73.58
13.55
76.65
13.88
14
41.51
7.22
49.42
8.78
57.55
10.39
61.50
11.23
65.45
12.08
73.58
13.82
75.77
14.04
16
41.51
7.36
49.42
8.94
57.55
10.61
61.50
11.45
65.45
12.32
73.14
13.99
74.68
14.21
18
41.51
7.50
49.42
9.11
57.55
10.80
61.50
11.67
65.45
12.57
72.26
14.45
73.80
14.56
20
41.51
7.63
49.42
9.30
57.55
11.12
61.50
12.27
65.45
13.47
71.16
15.13
72.70
15.27
21
41.51
7.72
49.42
9.38
57.55
11.53
61.50
12.70
65.45
13.93
70.73
15.49
72.26
15.62
23
41.51
7.91
49.42
10.01
57.55
12.35
61.50
13.60
65.45
14.94
69.85
16.19
71.16
16.33
25
41.51
8.42
49.42
10.69
57.55
13.22
61.50
14.59
65.45
16.00
68.75
16.90
70.28
17.04
27
41.51
9.00
49.42
11.40
57.55
14.12
61.50
15.60
65.45
17.12
67.65
17.61
69.19
17.78
29
41.51
9.57
49.42
12.16
57.55
15.08
61.50
16.66
65.23
18.18
66.77
18.35
68.31
18.48
31
41.51
10.20
49.42
12.98
57.55
16.08
61.50
17.78
64.35
18.89
65.68
19.06
67.21
19.22
33
41.51
10.82
49.42
13.82
57.55
17.15
61.50
18.98
63.26
19.60
64.80
19.77
66.33
19.96
35
41.51
11.50
49.42
14.70
57.55
18.29
61.50
20.23
62.16
20.31
63.70
20.50
65.23
20.67
37
41.51
12.24
49.42
15.65
57.55
19.49
60.39
20.94
61.28
21.05
62.82
21.24
64.14
21.40
39
41.51
13.00
49.42
16.63
57.55
20.75
59.52
21.65
60.18
21.76
61.72
21.95
63.26
22.17
41
41.51
13.61
49.42
17.24
57.55
21.51
58.60
21.80
59.72
22.09
60.65
22.46
62.34
22.62
43
40.79
13.96
48.56
17.52
56.54
21.51
56.67
21.65
58.25
21.90
59.94
22.20
60.17
22.46
46
40.79
14.75
48.56
18.32
56.54
21.88
55.46
21.95
57.95
22.30
59.44
22.54
58.96
22.76
48
40.79
15.40
48.56
18.96
56.54
21.91
53.18
22.20
57.86
22.69
55.81
22.78
57.67
22.97
50
40.31
15.49
47.98
19.05
55.90
22.01
52.75
22.31
57.29
22.78
55.17
22.90
57.04
23.08
52
39.82
15.53
47.25
19.13
55.17
22.09
51.79
22.39
56.38
22.90
54.45
22.98
56.38
23.16
55
39.10
15.63
46.53
19.27
54.20
22.27
51.06
22.57
55.65
23.04
53.48
23.12
55.41
23.34
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
