Part 2 - Outdoor Unit Engineering Data
Table 2-8.9: 24HP cooling capacity (continued)
Combination
(%)
(Capacity
index)
Outdoor
temperature
(°C DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
90%
-5
40.68
5.74
48.58
6.89
56.47
8.13
60.30
8.87
64.13
9.44
72.02
10.85
79.92
12.42
-2
40.68
5.80
48.58
6.96
56.47
8.23
60.30
8.99
64.13
9.55
72.02
10.95
79.92
12.54
0
40.68
5.88
48.58
7.05
56.47
8.36
60.30
9.10
64.13
9.67
72.02
11.08
79.92
12.64
2
40.68
5.97
48.58
7.14
56.47
8.45
60.30
9.24
64.13
9.82
72.02
11.31
79.92
12.83
4
40.68
6.06
48.58
7.24
56.47
8.59
60.30
9.36
64.13
9.95
72.02
11.48
79.92
13.01
6
40.68
6.15
48.58
7.39
56.47
8.75
60.30
9.54
64.13
10.12
72.02
11.66
79.92
13.23
8
40.68
6.26
48.58
7.53
56.47
8.92
60.30
9.66
64.13
10.30
72.02
11.88
79.92
13.36
10
40.68
6.38
48.58
7.69
56.47
9.09
60.30
9.81
64.13
10.53
72.02
12.03
79.92
13.57
12
40.68
6.49
48.58
7.83
56.47
9.25
60.30
9.97
64.13
10.73
72.02
12.26
79.92
13.82
14
40.68
6.60
48.58
7.97
56.47
9.42
60.30
10.17
64.13
10.92
72.02
12.48
79.92
14.07
16
40.68
6.72
48.58
8.11
56.47
9.62
60.30
10.37
64.13
11.15
72.02
12.74
79.68
14.32
18
40.68
6.83
48.58
8.28
56.47
9.78
60.30
10.56
64.13
11.37
72.02
12.99
78.73
14.77
20
40.68
6.97
48.58
8.47
56.47
9.98
60.30
10.79
64.13
11.79
72.02
13.96
77.53
15.47
21
40.68
7.02
48.58
8.53
56.47
10.14
60.30
11.15
64.13
12.21
72.02
14.46
77.05
15.83
23
40.68
7.16
48.58
8.86
56.47
10.87
60.30
11.96
64.13
13.10
72.02
15.52
75.85
16.55
25
40.68
7.55
48.58
9.48
56.47
11.62
60.30
12.79
64.13
13.99
72.02
16.61
74.90
17.28
27
40.68
8.03
48.58
10.09
56.47
12.40
60.30
13.66
64.13
14.97
72.02
17.78
73.70
18.00
29
40.68
8.56
48.58
10.76
56.47
13.24
60.30
14.58
64.13
16.00
71.30
18.59
72.74
18.73
31
40.68
9.09
48.58
11.45
56.47
14.10
60.30
15.55
64.13
17.06
70.11
19.31
71.55
19.48
33
40.68
9.64
48.58
12.18
56.47
15.05
60.30
16.58
64.13
18.20
69.15
20.06
70.59
20.20
35
40.68
10.26
48.58
12.96
56.47
16.02
60.30
17.67
64.13
19.40
67.96
20.79
69.39
20.96
37
40.68
10.87
48.58
13.77
56.47
17.06
60.30
18.81
64.13
20.68
66.76
21.52
68.43
21.68
39
40.68
11.54
48.58
14.66
56.47
18.14
60.30
20.04
64.13
22.02
65.81
22.27
67.24
22.43
41
40.68
11.94
48.58
15.32
56.47
18.81
60.30
20.57
64.13
22.15
65.35
22.83
66.79
22.96
43
40.68
12.51
48.58
15.99
56.47
19.47
60.30
21.10
64.13
22.62
65.01
23.13
66.21
23.32
46
40.68
13.30
48.58
16.78
56.47
20.26
60.30
21.81
64.13
23.25
64.65
23.37
65.20
23.63
48
40.68
14.04
48.58
17.55
56.47
21.03
60.30
22.08
64.13
23.45
64.11
23.70
63.44
23.95
50
40.16
14.12
48.12
17.63
55.84
21.15
59.82
22.19
63.56
23.57
63.56
23.80
62.77
24.08
52
39.62
14.15
47.34
17.70
55.05
21.22
58.73
22.26
62.47
23.66
62.47
23.92
61.93
24.15
55
39.07
14.28
46.55
17.83
54.21
21.38
57.95
22.46
61.45
23.84
61.45
24.08
60.90
24.35
80%
-5
36.13
5.06
43.07
5.98
50.01
7.08
53.60
7.53
57.19
8.11
64.13
9.38
71.07
10.70
-2
36.13
5.13
43.07
6.06
50.01
7.14
53.60
7.65
57.19
8.19
64.13
9.47
71.07
10.81
0
36.13
5.22
43.07
6.13
50.01
7.23
53.60
7.74
57.19
8.33
64.13
9.60
71.07
10.95
2
36.13
5.33
43.07
6.22
50.01
7.34
53.60
7.89
57.19
8.48
64.13
9.79
71.07
11.16
4
36.13
5.42
43.07
6.33
50.01
7.48
53.60
8.07
57.19
8.63
64.13
9.97
71.07
11.31
6
36.13
5.51
43.07
6.47
50.01
7.59
53.60
8.25
57.19
8.80
64.13
10.12
71.07
11.50
8
36.13
5.61
43.07
6.62
50.01
7.77
53.60
8.38
57.19
8.99
64.13
10.27
71.07
11.73
10
36.13
5.66
43.07
6.77
50.01
7.97
53.60
8.58
57.19
9.20
64.13
10.51
71.07
11.85
12
36.13
5.74
43.07
6.88
50.01
8.11
53.60
8.75
57.19
9.39
64.13
10.70
71.07
12.07
14
36.13
5.85
43.07
7.02
50.01
8.25
53.60
8.89
57.19
9.56
64.13
10.90
71.07
12.29
16
36.13
5.94
43.07
7.14
50.01
8.42
53.60
9.06
57.19
9.73
64.13
11.12
71.07
12.51
18
36.13
6.05
43.07
7.28
50.01
8.58
53.60
9.25
57.19
9.92
64.13
11.34
71.07
12.77
20
36.13
6.16
43.07
7.41
50.01
8.75
53.60
9.42
57.19
10.12
64.13
11.76
71.07
13.66
21
36.13
6.22
43.07
7.47
50.01
8.83
53.60
9.53
57.19
10.34
64.13
12.18
71.07
14.16
23
36.13
6.33
43.07
7.64
50.01
9.25
53.60
10.14
57.19
11.06
64.13
13.04
71.07
15.19
25
36.13
6.52
43.07
8.11
50.01
9.89
53.60
10.84
57.19
11.82
64.13
13.96
71.07
16.25
27
36.13
6.94
43.07
8.64
50.01
10.54
53.60
11.57
57.19
12.63
64.13
14.91
71.07
17.39
29
36.13
7.39
43.07
9.20
50.01
11.23
53.60
12.32
57.19
13.49
64.13
15.91
71.07
18.59
31
36.13
7.83
43.07
9.78
50.01
11.96
53.60
13.13
57.19
14.38
64.13
17.00
69.87
19.32
33
36.13
8.33
43.07
10.40
50.01
12.74
53.60
13.99
57.19
15.30
64.13
18.12
68.91
20.04
35
36.13
8.83
43.07
11.06
50.01
13.55
53.60
14.88
57.19
16.30
64.13
19.32
67.72
20.76
37
36.13
9.36
43.07
11.73
50.01
14.41
53.60
15.86
57.19
17.36
64.13
20.60
66.76
21.49
39
36.13
9.92
43.07
12.51
50.01
15.33
53.60
16.86
57.19
18.48
64.13
21.94
65.56
22.24
41
36.13
10.15
43.07
12.63
50.01
15.55
53.60
17.31
57.19
18.81
64.13
22.49
65.16
22.63
43
36.13
10.44
43.07
12.74
50.01
15.78
53.60
17.61
57.19
19.07
64.13
22.75
64.76
22.87
46
36.13
10.74
43.07
12.89
50.01
16.08
53.60
17.98
57.19
19.40
64.13
23.00
63.96
23.25
48
36.13
11.09
43.07
12.96
50.01
16.33
53.60
18.22
57.19
19.56
64.13
23.22
63.42
23.55
50
35.91
11.15
42.56
13.04
49.47
16.40
53.17
18.32
56.66
19.68
63.57
23.34
62.78
23.69
52
35.38
11.19
42.02
13.08
48.67
16.48
52.37
18.37
55.85
19.75
62.50
23.43
61.96
23.77
55
34.57
11.27
41.22
13.20
47.86
16.59
51.30
18.51
54.78
19.87
61.43
23.61
60.90
23.96
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
