Midea VC Pro Series Engineering Data Book
Table 2-8.10: 26HP cooling capacity (continued)
Combination
(%)
(Capacity
index)
Outdoor
temperature (°C
DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
90%
-5
44.32
6.50
52.93
7.80
61.53
9.20
65.70
10.04
69.87
10.68
78.47
12.28
87.08
14.06
-2
44.32
6.56
52.93
7.88
61.53
9.32
65.70
10.18
69.87
10.81
78.47
12.40
87.08
14.20
0
44.32
6.66
52.93
7.98
61.53
9.46
65.70
10.30
69.87
10.94
78.47
12.54
87.08
14.30
2
44.32
6.76
52.93
8.08
61.53
9.56
65.70
10.46
69.87
11.12
78.47
12.80
87.08
14.51
4
44.32
6.86
52.93
8.20
61.53
9.72
65.70
10.60
69.87
11.26
78.47
13.00
87.08
14.73
6
44.32
6.95
52.93
8.36
61.53
9.90
65.70
10.80
69.87
11.45
78.47
13.20
87.08
14.97
8
44.32
7.09
52.93
8.52
61.53
10.10
65.70
10.94
69.87
11.65
78.47
13.44
87.08
15.11
10
44.32
7.22
52.93
8.70
61.53
10.28
65.70
11.10
69.87
11.92
78.47
13.62
87.08
15.36
12
44.32
7.35
52.93
8.86
61.53
10.47
65.70
11.29
69.87
12.14
78.47
13.88
87.08
15.64
14
44.32
7.47
52.93
9.02
61.53
10.66
65.70
11.51
69.87
12.36
78.47
14.13
87.08
15.92
16
44.32
7.60
52.93
9.18
61.53
10.88
65.70
11.73
69.87
12.61
78.47
14.41
86.82
16.21
18
44.32
7.73
52.93
9.37
61.53
11.07
65.70
11.95
69.87
12.87
78.47
14.69
85.78
16.71
20
44.32
7.88
52.93
9.58
61.53
11.29
65.70
12.20
69.87
13.34
78.47
15.80
84.47
17.50
21
44.32
7.95
52.93
9.65
61.53
11.48
65.70
12.61
69.87
13.81
78.47
16.37
83.95
17.91
23
44.32
8.11
52.93
10.03
61.53
12.30
65.70
13.53
69.87
14.82
78.47
17.56
82.64
18.73
25
44.32
8.54
52.93
10.72
61.53
13.15
65.70
14.47
69.87
15.83
78.47
18.80
81.61
19.55
27
44.32
9.08
52.93
11.42
61.53
14.03
65.70
15.45
69.87
16.93
78.47
20.12
80.30
20.37
29
44.32
9.68
52.93
12.17
61.53
14.98
65.70
16.49
69.87
18.10
77.69
21.03
79.25
21.19
31
44.32
10.28
52.93
12.96
61.53
15.96
65.70
17.60
69.87
19.30
76.39
21.85
77.95
22.04
33
44.32
10.91
52.93
13.78
61.53
17.03
65.70
18.76
69.87
20.59
75.34
22.70
76.91
22.86
35
44.32
11.60
52.93
14.66
61.53
18.13
65.70
19.99
69.87
21.95
74.04
23.53
75.61
23.71
37
44.32
12.30
52.93
15.58
61.53
19.30
65.70
21.29
69.87
23.40
72.74
24.35
74.56
24.53
39
44.32
13.06
52.93
16.59
61.53
20.53
65.70
22.67
69.87
24.91
71.70
25.20
73.26
25.39
41
44.32
13.51
52.93
17.34
61.53
21.28
65.70
23.27
69.87
25.06
71.20
25.84
72.77
25.98
43
44.03
14.06
52.58
17.97
61.13
21.88
65.27
23.72
69.42
25.43
70.37
26.00
71.67
26.21
46
44.03
14.96
52.58
18.86
61.13
22.78
65.27
24.51
69.42
26.13
69.98
26.27
70.57
26.56
48
44.03
15.79
52.58
19.73
61.13
23.63
65.27
24.82
69.42
26.36
69.39
26.64
68.67
26.92
50
43.47
15.87
52.09
19.82
60.44
23.77
64.75
24.95
68.80
26.49
68.80
26.75
67.95
27.07
52
42.88
15.91
51.24
19.90
59.59
23.85
63.57
25.02
67.62
26.59
67.62
26.89
67.03
27.15
55
42.30
16.05
50.39
20.04
58.68
24.03
62.72
25.24
66.51
26.79
66.51
27.07
65.92
27.37
80%
-5
39.37
5.73
46.93
6.77
54.49
8.02
58.40
8.52
62.31
9.18
69.87
10.61
77.43
12.11
-2
39.37
5.81
46.93
6.85
54.49
8.08
58.40
8.66
62.31
9.26
69.87
10.71
77.43
12.23
0
39.37
5.91
46.93
6.94
54.49
8.18
58.40
8.76
62.31
9.43
69.87
10.86
77.43
12.39
2
39.37
6.03
46.93
7.04
54.49
8.30
58.40
8.93
62.31
9.60
69.87
11.08
77.43
12.63
4
39.37
6.13
46.93
7.16
54.49
8.46
58.40
9.13
62.31
9.77
69.87
11.28
77.43
12.80
6
39.37
6.23
46.93
7.33
54.49
8.59
58.40
9.33
62.31
9.95
69.87
11.45
77.43
13.02
8
39.37
6.35
46.93
7.49
54.49
8.79
58.40
9.48
62.31
10.17
69.87
11.62
77.43
13.27
10
39.37
6.40
46.93
7.66
54.49
9.02
58.40
9.71
62.31
10.41
69.87
11.89
77.43
13.40
12
39.37
6.50
46.93
7.79
54.49
9.18
58.40
9.90
62.31
10.63
69.87
12.11
77.43
13.66
14
39.37
6.62
46.93
7.95
54.49
9.33
58.40
10.06
62.31
10.82
69.87
12.33
77.43
13.91
16
39.37
6.72
46.93
8.07
54.49
9.52
58.40
10.25
62.31
11.01
69.87
12.58
77.43
14.16
18
39.37
6.84
46.93
8.23
54.49
9.71
58.40
10.47
62.31
11.23
69.87
12.84
77.43
14.44
20
39.37
6.97
46.93
8.39
54.49
9.90
58.40
10.66
62.31
11.45
69.87
13.31
77.43
15.45
21
39.37
7.03
46.93
8.45
54.49
10.00
58.40
10.78
62.31
11.70
69.87
13.78
77.43
16.02
23
39.37
7.16
46.93
8.64
54.49
10.47
58.40
11.48
62.31
12.52
69.87
14.76
77.43
17.19
25
39.37
7.38
46.93
9.18
54.49
11.20
58.40
12.27
62.31
13.37
69.87
15.80
77.43
18.39
27
39.37
7.85
46.93
9.78
54.49
11.92
58.40
13.09
62.31
14.29
69.87
16.87
77.43
19.68
29
39.37
8.36
46.93
10.41
54.49
12.71
58.40
13.94
62.31
15.26
69.87
18.01
77.43
21.04
31
39.37
8.86
46.93
11.07
54.49
13.53
58.40
14.85
62.31
16.27
69.87
19.24
76.13
21.86
33
39.37
9.43
46.93
11.76
54.49
14.41
58.40
15.83
62.31
17.31
69.87
20.50
75.08
22.67
35
39.37
10.00
46.93
12.52
54.49
15.33
58.40
16.84
62.31
18.45
69.87
21.86
73.78
23.49
37
39.37
10.60
46.93
13.28
54.49
16.31
58.40
17.94
62.31
19.65
69.87
23.31
72.74
24.32
39
39.37
11.23
46.93
14.16
54.49
17.35
58.40
19.08
62.31
20.91
69.87
24.82
71.43
25.17
41
39.37
11.48
46.93
14.29
54.49
17.60
58.40
19.59
62.31
21.29
69.87
25.45
71.00
25.61
43
39.11
11.74
46.62
14.32
54.13
17.73
58.02
19.79
61.91
21.44
69.41
25.58
70.10
25.71
46
39.11
12.07
46.62
14.48
54.13
18.08
58.02
20.21
61.91
21.81
69.41
25.86
69.23
26.14
48
39.11
12.46
46.62
14.57
54.13
18.35
58.02
20.48
61.91
21.98
69.41
26.10
68.65
26.47
50
38.87
12.53
46.07
14.66
53.55
18.44
57.55
20.59
61.33
22.12
68.81
26.23
67.95
26.63
52
38.29
12.58
45.49
14.71
52.68
18.52
56.68
20.64
60.45
22.20
67.65
26.33
67.07
26.72
55
37.42
12.66
44.62
14.84
51.81
18.65
55.52
20.81
59.29
22.33
66.49
26.53
65.92
26.93
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
Shaded cells indicate rating condition.
Table continued on next page …
