Operation
1. Side brush installed: directly pushing the side brush into the central convex
shaft situated at the side brush seat (fig 1).
2. Sweeping operation: Press to start/stop sweeping (fig 2).
3. Place charging base (fig 3).
4. Recharge operation: Press to enable the machine to recharge
automaticly (fig 4). After the machine contacting with the charging base,
giving the sound of beep, the indicator flashes to indicate that the main
engine is charging (fig 5).
fig 1
fig 2
fig 3
fig 4
fig 5
1.5 m
1.5 m
1.5 m
1.5 m
EN-13
