W Page 19 X
Installation
Instructions
4. Install Air Conditioner
NOTICE
Measure the width of your window
track (the vertical track your window
slides up and down in) before installing
your air conditioner. If it measures 1/2“
or less, flip the Anti-Tip Bracket so the
small end faces out, then continue with
your air conditioner installation.
A. Set the air conditioner on top of the
support bracket. Ensure the grooves
on the bottom of the air conditioner
align with the Main Supports. Using
a level, check for proper tilt towards
the outside.
WARNING
Do not leave the unit unattended during
installation.
B. Pull the window down into the slot to help align the unit in the correct location. Keep
the window partially inserted into the window slot to help support the air conditioner
during installation.
Fold down both Side Arm Hinges.
Fig. 12
Fig. 13
Fig. 15
Fig. 14
This side faces indoors
To Next Page
