W Page 23 X
Installation
Instructions
E. Install a strip of Window Sealing
Foam to the bottom of your lower
sash sealing any small gaps between
the window and air conditioner. Then
close the window and check for gaps.
Fill any gaps with the included foam
as needed.
F. Extend the Integrated Window Locks
(located in the U channel) until they
contact the window. For additional
security you can install the optional
Sash Lock as shown.
Fig. 25
Fig. 26
FOAM SEAL
Fig. 24
G. To secure the lower sash in place,
attach right angle sash lock with 1/2”
Type A Screws as shown.
H. Cut window sash foam and insert it
in the space between the upper and
lower sashes.
Window Sash Foam
Window Sash Foam
To Next Page
