Page 20
Installation
Instructions
WARNING
Failing to install the Open Window Brackets
could cause injury or property damage.
C. Next, you must install the Open
Window Brackets using the provided
screws as shown.
Use the 1/2” Type B screw.
Use the 1/4”
Type B screw.
Fig. 16
A. Measure the distance
between the Side Arm
Hinge and the closest
part of the window frame
in line with the Side Arm.
Add 1/4” to this distance
and cut the Side Arm
Foam to length.
WARNING
Do not leave the unit
unattended during
installation.
5. Foam Installation
Fig. 17
To Next Page
