The Specification of Power
M Floor-standing Type 97
8. The Specification of Power
Model(Btu/h)
24000
POWER
Phase
1-phase
Frequency and Voltage
220-240V, 50Hz
POWER WIRING (mm
2
)
3×2.5
CIRCUIT BREAKER/Fuse (A)
30/20
Indoor/Outdoor Connecting Wiring(Weak Electric Signal) (mm
2
)
2×0.2
Indoor/Outdoor Connecting Wiring(Strong Electric Signal)(mm
2
)
3×1.0
Model(KBtu/h)
36
36
48
48
Indoor Power
Phase
1-phase
1-phase
1-phase
1-phase
Frequency and
Voltage
220-240V, 50Hz
220-240V, 50Hz
220-240V, 50Hz
220-240V, 50Hz
Circuit Breaker/
Fuse (A)
15/10
15/10
15/10
15/10
Outdoor Power
Phase
1-phase
3-phase
1-phase
3-phase
Frequency and
Voltage
220-240V, 50Hz
380-415V, 50Hz
220-240V, 50Hz
380-415V, 50Hz
Circuit Breaker/
Fuse (A)
40/30
25/20
50/40
32/25
Indoor Unit Power Wiring (mm
2
)
3×1.5
3×1.5
3×1.5
3×1.5
Indoor/Outdoor Connecting
Wiring (mm
2
)
Ground Wiring
4.0
2.5
4.0
2.5
Outdoor Unit
Power Wiring
3×4.0
5×2.5
3×4.0
5×2.5
Strong Electric
Signal
Weak Electric
Signal
(2×0.2)
(2×0.2)
(2×0.2)
(2×0.2)
Model(Btu/h)
55
POWER
Phase
3-phase
Frequency and Voltage
380-415V, 50Hz
POWER WIRING (mm
2
)
5×2.5
CIRCUIT BREAKER/Fuse (A)
32/25
Indoor/Outdoor Connecting Wiring(Weak Electric Signal) (mm
2
)
2×0.2
Indoor/Outdoor Connecting Wiring(Strong Electric Signal)(mm
2
)
