EN-16
COUNTERTOP INSTALLATION
INSTALLATION
2. Plug microwave oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frenquency on the rating label.
NOTE
• Do not install oven over a range cooktop
or other heat-producing appliance.
If installed near or over a heat source, the
oven could be damaged and the warranty
would be avoid.
The accessible surface may be
hot during operation
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
b. Leave a minimum clearance of 3.0 inches on each side, 3.0 inches on top and 1.0 inch in the rear.
c.Do not remove the legs from the bottom of the oven.
d
.Block ing the intake and/or outlet openings can damage the oven.
e.
Please place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV reception.
3.0 inches(7.5cm)
3.0 inches
(7.5cm)
3.0 inches
(7.5cm)
>3.0 ft
(91.6cm)
1.0 inch
(2.5cm)
a. The minimum installation height is 3.0 ft.
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not
remove the light brown waveguide cover that is attached to the oven cavity to protect the
magnetron.
To Next Page
