Midea X8 - Rolling Brush Cleaning

a
b
Notes
Wash the rolling brush with fresh water.
3
After cleaning, pinch the brush handle with
your hand, align the right side of the brush
shown in Figure a with the right end cover
first, then put the left end of the brush
handle shown in Figure b into the slot, and
the brush will be successfully installed.
4
Pull the handle on the left end of the rolling
brush to remove the rolling brush.
1
Remove the rolling brush, open the rotation
blade of the cleaning brush to remove the
things tangled on the brush such as hair.
2
Use of Product
Cleaning of rolling brush
If residual stains are found on the mouth of the suction nozzle, wipe with a damp rag,
and do not rinse it with water;
After using the machine each time, clean and dry the rolling brush timely to keep it clean
and tidy.
Pull up
14
