Midea YL2037S-B

YL2037S-B
YL1632S-W
PRODUCT INSTALLATION
10
Activate Heating & Cooling
Notice: This unit will not dispense hot or cold water until the switches are activated, and
make sure water comes out of taps before activating heating or cooling switch;
To activate, push power switches on the left side in to start heating and cooling water
and the heating pilot lamp or cooling pilot lamp is on at the same time.
- If you do not want to heat water, push bottom side of red switch to the OFF position.
- If you do not want to cool water, push bottom side of green switch to the OFF
position.
1. Use the screw to fix the bracket on the hole of the
middle bottom of the water dispenser.
2. Make a hole on the floor's surface where the water
dispenser will be installed.
3. Fix the bracket on the floor by screw tightly.
4. Tighten the screw.
MACHINE INSTALLATION
WARNING! To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
WARNING! To avoid a hazard due to instability of the appliance, it must be fixed in
accordance with the instructions.
1 2 3 4
Water dispenser
Bracket
The hole for
tighten screw
Instructions for installation:
water dispenser
The hole for
tighten screw
1. The right as the picture shown.
2. Make a hole on the floor’s or the desk’s surface where
the water dispenser will be installed.
3. Use the screw to fix the bracket on the left
bottom angle of the water dispenser.
4. Fix the machine on the ground or the table.
1
2 3
4
