5
OPERATION
ANI Encode: When the PTT Input is grounded, the unit will assert the PTT Output and send the programmed
ANI tones out the TX Tone Output.
ENI Encode: When the Emergency Input is grounded for the programmed amount of time, the unit will assert the
PTT Output and send the programmed Emergency ANI tones out the TX Tone Output. Cycling the power to the
unit or grounding the PTT Input will cancel the ENI.
Burst Tone Encode: When the PTT Input is grounded the ANI-F will encode the burst tone associated with the 2-
line binary configuration.
POCSAG: When the an input changes state the ANI-F will assert the PTT Output and generate the POCSAG
page associated with the state of that input.
TECHNICAL NOTES
Programming 2-tone: 2-tone ANI is programmed with the Advanced Tone Definitions. In Frame 1, Frequency 1
type in the frequency of the first tone and type the length of the first tone in Frame 1 msec. In Frame 2, Frequency
1 type in the frequency of the second tone and type the length of the second tone in Frame 2 msec. If a gap is
needed set Frame 2 Frequency 1 to 0 and the desired length of the gap in Frame 2 msec. Frame 3 would then
be the second tone.
MIDIAN CONTACT INFORMATION
Midian Electronics Inc.
2302 East 22
nd
Street
Tucson, Arizona 85713 USA
Orders: 1-800-MIDIANS
Phone: 520-884-7981
Fax: 520-884-0422
E-mail: sales@midians.com
Web: http://www.midians.com/
